7IE 10 – Grill / Smooth

Moduler Cooking

İNOKSAN 7IE 10 – Grill / Smooth
Puan 4.4/5 Yorum 511
9.04.2025
4.2/ 5

Features

  • Width: 40 cm
  • Depth: 76 cm
  • Height: 94 cm
  • Pallet box dimensions: 422x772x1006 mm
More Information

General features

Width 40 cm
Depth 76 cm
Height 94 cm
Pallet box dimensions 422x772x1006 mm

Functional Features

Technicial Specifications

Electric Input 380/400 V
Total power 4,5 kW
Max. Electric power 4,5 kW
Frequency 50-60 Hz
Cable cross section 5x2,5 mm²

Accessory

GENERAL FEALTURES

  • Fry Top
  • Perfect 700 line, 1/2 module, with cabinet
  • Smooth surface,
  • Body manufactured of 18/8 Cr-Ni s/s stain finished sheet and inner parts of alumunized steel,
  • Oil collecting channel and discharge in front of the frying surface,
  • Collecting of oil on the surface in a easy to clean s/s drawer,
  • Upstands at 3 ends in order to prevent fat from splashing around during frying process,
  • All of the electric control borads and devices in conformity with the international standards,
  • Temperature adjustment between 50-300°C by multi-step thermostat and with safety thermostat of  350°C,
  • Main switch for the supply or stop of the power,
  • It is manufactured with cabinet as standart. Cabinet is manufactured from stainless stell. Cabinet doors are with plastic holder,
  • For multi-purpose use, on a cupboard (with or without doors) or on cantilever for island type installations,
  • Adjustable feet of stainless stell pipe, carrier sheet is 2 mm aluminized sheet,

TECHNICAL SPECIFICATION

Total Power

4,5

kW

Electric Inlet

380-400

V

Cooking area

394x489.5

mm

Cablo cut

5x2,5

mm²

Palett+Box Measures

422x772x1006

AxDxH

ELEKTRİKLİ IZGARA KULLANIM KILAVUZU
ELEKTRİKLİ IZGARA KULLANIM KILAVUZU

Request/Information Form

7IE 10 – Grill / Smooth
